24C256-SMD (AT24C256C-SSHL-T)
63,74 TL
SMD Serial EEPROM
| Density | 256Kb |
| Interface Type | Serial (2-Wire) |
| Organization | 32Kx8 |
| Access Time (Max) | 550ns |
| Frequency | 1MHz |
| Write Protection | Yes |
| Data Retention | 40Year |
| Operating Supply Voltage (Typ) | 1.8/2.5/3.3/5V |
| Package Type | SOIC |
| Packaging | Tape and Reel |
| Operating Temp Range | -40C to 85C |
| Supply Current | 3mA |
| Operating Supply Voltage (Min) | 1.7V |
| Operating Supply Voltage (Max) | 5.5V |
| Operating Temperature Classification | Industrial |
| Mounting | Surface Mount |
| Pin Count | 8 |
