| Category | Discrete Semiconductors/IGBTs/Single IGBTs |
|
| Manufacturer | CRMICRO |
|
| Package | TO-247 |
|
| Td(off) | 238ns |
|
| Pd - Power Dissipation | 333W |
|
| Td(on) | 77ns |
|
| Operating Temperature | -40℃~+175℃ |
|
| Collector-Emitter Breakdown Voltage (Vces) | 1.2kV |
|
| Reverse Transfer Capacitance (Cres) | 111pF |
|
| Gate-Emitter Threshold Voltage (Vge(th)@Ic) | 5V@250uA |
|
| Gate Charge(Qg) | 208nC@15V |
|
| Pulsed Current- Forward(Ifm) | 160A |
|
| Output Capacitance(Coes) | 131pF |
|
| Reverse Recovery Time(trr) | 88ns |
|
| Switching Energy(Eoff) | 1.5mJ |
|
| Turn-On Energy (Eon) | 2.8mJ |
