F3AA024E
41,79 TL
0 Puan / 0 Yorum
| Contact Current (Nom) | 5A | |
| Series | FTR-F3-HA | |
| Contact Form | SPST-NO (1 Form A) | |
| Coil Type | Non Latching | |
| Coil Voltage | 24VDC | |
| Number of Pins | 4 Pin | |
| Rohs | ROHS | |
| Packaging | TRAY | |
| Contact Voltage | 277VAC/30VDC - Max | |
| Relay Type | Relay Power Slim | |
| Operating Temperature | -40°C~+70°C | |
| Length | 20.30mm | |
| Height | 15.00mm | |
| Mounting Type | THT | |
| Coil Resistance | 2.88K Ohms | |
| Coil Power | 200mW | |
| Width | 7.00mm |
