IDC Connector 1Pin (3924N)
26,51 TL
| Features |
| • Insulated IDC connectors, modular • For kables with wire size 0,2...0,5mm2 • Max. wire outside diameter 2,1mm • For easy connection without tools • Strip, solder or screw necessary • 3924N.1: Connecting plate as security for 3924N (must be ordered separately) |
 |
| Applicable Wire |
| • UL1007 AWG24...AWG20 • KV (per JIS) 0,2...0,5mm2 • KIV (per JIS) 0,3mm2 • VFS ((JIS) 0,3mm2 |
|
| Technical Specifications |
|
|
| Material |
|
| Contact: |
Pre-tin plated bronze |
| Housing: |
Polycarbonate (black) |
| Cover: |
Polycarbonate (yellow and translucent) |
| Connecting Plate: |
Polycarbonate (white) |
| Rated Voltage: |
100V DC |
| Max. Rated Current |
|
| 0,2mm2: |
2A |
| 0,5mm2: |
3A |
| Temperature Range: |
-20...+75°C |
| Assemble temperature: |
0...+40°C |
